Sorting in NumPy

If you are into Python programming and are manipulating data, you should learn NumPy. NumPy  is an extension to the Python programming language, adding support for large, multi-dimensional arrays and matrices, along with a large library of high-level mathematical functions to operate on these arrays.

To use NumPy in your Python code, import the numpy module:

import numpy as np

To see how NumPy is useful, consider the following example:

persons = np.array(['Johnny','Mary','Peter','Will','Joe'])
ages = np.array([34,12,37,5,13])
heights = np.array([1.76,1.2,1.68,0.5,1.25])

In the above code snippet, I created three NumPy arrays to store a list of persons’ name, as well as their corresponding age and height. NumPy arrays are similar to Python’s list, except that NumPy arrays contains elements of the same type. Let’s print them out and example their contents:

print '---Before sorting---'
print persons
print ages
print heights

You should see the following:

---Before sorting---
['Johnny' 'Mary' 'Peter' 'Will' 'Joe']
[34 12 37  5 13]
[ 1.76  1.2   1.68  0.5   1.25]

Suppose we want to sort the elements based on certain axis, such as ages. After the sort, you would want to print the sorted ages as well as the corresponding name and height. For this purpose, you can use the argsort() function in NumPy:

sort_indices = np.argsort(ages)  # performs a sort based on ages
                                 # and returns an array of indices
                                 # indicating the sort order

The argsort() function returns a list of indices, which you can examine by printing it out:

print '---Sort indices---'
print sort_indices

You should see the following:

---Sort indices---
[3 1 4 0 2]

To print the all the other arrays sorted by age, you can now pass the sort indices into the individual arrays, like this:

print '---After sorting---'
print persons[sort_indices]
print ages[sort_indices]
print heights[sort_indices]

This will print out the following:

---After sorting---
['Will' 'Mary' 'Joe' 'Johnny' 'Peter']
[ 5 12 13 34 37]
[ 0.5   1.2   1.25  1.76  1.68]

The argsort() function also works for strings, like this:

sort_indices = np.argsort(persons)
print persons[sort_indices]
print ages[sort_indices]
print heights[sort_indices]
'''
prints out the following:
['Joe' 'Johnny' 'Mary' 'Peter' 'Will']
[13 34 12 37  5]
[ 1.25  1.76  1.2   1.68  0.5 ]
'''

Sorting in Reverse Order

The argsort() function only sorts in ascending order. So what happens if you need to sort in descending order? Well, easy! In Python, [::-1] reverses the order of a list. This applies to NumPy arrays too.

Hence, to sort the persons’ names in descending order, first sort it in ascending order and then reverse the result, like this:

reverse_sort_indices = np.argsort(persons)[::-1]
print persons[reverse_sort_indices]
print ages[reverse_sort_indices]
print heights[reverse_sort_indices]

The above code snippet prints out the following:

['Will' 'Peter' 'Mary' 'Johnny' 'Joe']
[ 5 37 12 34 13]

[ 0.5   1.68  1.2   1.76  1.25]

Learning More

This article is just touching on the surface of what Python can do in the world of data analytics. To learn more about using Python for data analysis, come join my workshop (Introduction to Data Science using Python) at NDC Sydney 2016 on the 1-2 August 2016. See you there!

Wednesday, May 18, 2016

Data Visualization Using Python, Pandas and Matplotlib

Internet of Things (IoT) has been the buzzwords of late. While most people associate IoT with the collection of data using sensors and transmitted to central servers, an integral part of IoT involves processing the data collected. The ability to visualize data and make intelligent decisions is the cornerstone of IoT systems.

Python is one of the preferred languages for data analytics, due to its ease of learning and its huge community support of modules and packages designed for number crunching. In this article, I am going to show you the power of Python and how you can use it to visualize data.

Collection of Blood Glucose Data

With the advancement in technologies, heathcare is one area that is receiving a lot of attention. One particular disease – diabetes, garners a lot of attention. According to the World Health Organization (WHO), the number of people with diabetes has risen from 108 million in 1980 to 422 million in 2014. The care and prevention of diabetes is hence of paramount importance. Diabetics need to regular prick their fingers to measure the amount of blood sugar in their body.

For this article, I am going to show you how to visualize the data collected by a diabetic so that he can see at a glance on how well he is keeping diabetes in control.

Storing the Data

For this article, I am assuming that you have a CSV file named readings.csv, which contains the following lines:

,DateTime,mmol/L
0,2016-06-01 08:00:00,6.1
1,2016-06-01 12:00:00,6.5
2,2016-06-01 18:00:00,6.7
3,2016-06-02 08:00:00,5.0
4,2016-06-02 12:00:00,4.9
5,2016-06-02 18:00:00,5.5
6,2016-06-03 08:00:00,5.6
7,2016-06-03 12:00:00,7.1
8,2016-06-03 18:00:00,5.9
9,2016-06-04 09:00:00,6.6
10,2016-06-04 11:00:00,4.1
11,2016-06-04 17:00:00,5.9
12,2016-06-05 08:00:00,7.6
13,2016-06-05 12:00:00,5.1
14,2016-06-05 18:00:00,6.9
15,2016-06-06 08:00:00,5.0
16,2016-06-06 12:00:00,6.1
17,2016-06-06 18:00:00,4.9
18,2016-06-07 08:00:00,6.6
19,2016-06-07 12:00:00,4.1
20,2016-06-07 18:00:00,6.9
21,2016-06-08 08:00:00,5.6
22,2016-06-08 12:00:00,8.1
23,2016-06-08 18:00:00,10.9
24,2016-06-09 08:00:00,5.2
25,2016-06-09 12:00:00,7.1
26,2016-06-09 18:00:00,4.9

The CSV file contains rows of data that are divided into three columns – index, date and time, and blood glucose readings in mmol/L.

Reading the Data in Python

While Python supports lists and dictionaries for manipulating structured data, it is not well suited for manipulating numerical tables, such as the one stored in the CSV file. As such, you should use pandas. Pandas is a software library written for Python for data manipulation and analysis.

Let’s see how pandas work. Note that for this article, I am using IPython Notebook for running my Python script. The best way to use IPython Notebook is to download Anaconda (https://www.continuum.io/downloads). Anaconda comes with the IPython Notebook, as well as pandas and matplotlib (more on this later).

Once Anaconda is installed, launch the IPython Notebook by typing the following command in Terminal:

$ ipython notebook

When IPython Notebook has started, click on New | Python 2:




Type the following statements into the cell:

import pandas as pd
data_frame = pd.read_csv('readings.csv', index_col=0, parse_dates=[1])
print data_frame

You first import the pandas module as pd, then you use the read_csv() function read the data from the CSV file to create a dataframe. A dataframe in pandas behaves like a two-dimensional array, with an index for each row. The index_col parameter specifies which column in the CSV file will be used as the index (column 0 in this case) and the parse_dates parameter specifies the column that should be parsed as a datetime object (column 1 in this case). To run the Python script in the cell, press Ctrl-Enter.

When you print out the dataframe, you should see the following:

              DateTime  mmol/L
0  2016-06-01 08:00:00     6.1
1  2016-06-01 12:00:00     6.5
2  2016-06-01 18:00:00     6.7
3  2016-06-02 08:00:00     5.0
4  2016-06-02 12:00:00     4.9
5  2016-06-02 18:00:00     5.5
6  2016-06-03 08:00:00     5.6
7  2016-06-03 12:00:00     7.1
8  2016-06-03 18:00:00     5.9
9  2016-06-04 09:00:00     6.6
10 2016-06-04 11:00:00     4.1
11 2016-06-04 17:00:00     5.9
12 2016-06-05 08:00:00     7.6
13 2016-06-05 12:00:00     5.1
14 2016-06-05 18:00:00     6.9
15 2016-06-06 08:00:00     5.0
16 2016-06-06 12:00:00     6.1
17 2016-06-06 18:00:00     4.9
18 2016-06-07 08:00:00     6.6
19 2016-06-07 12:00:00     4.1
20 2016-06-07 18:00:00     6.9
21 2016-06-08 08:00:00     5.6
22 2016-06-08 12:00:00     8.1
23 2016-06-08 18:00:00    10.9
24 2016-06-09 08:00:00     5.2
25 2016-06-09 12:00:00     7.1
26 2016-06-09 18:00:00     4.9

You can print out the index of the dataframe by using the index property:

print data_frame.index

You should see the index as follows:

Int64Index([ 0,  1,  2,  3,  4,  5,  6,  7,  8,  9, 10, 11, 12, 13, 14, 15, 16,
            17, 18, 19, 20, 21, 22, 23, 24, 25, 26],
           dtype='int64')

You can also print out the individual columns of the dataframe:

print data_frame['DateTime']

This should print out the DateTime column of the dataframe:

0    2016-06-01 08:00:00
1    2016-06-01 12:00:00
2    2016-06-01 18:00:00
3    2016-06-02 08:00:00
4    2016-06-02 12:00:00
5    2016-06-02 18:00:00
6    2016-06-03 08:00:00
7    2016-06-03 12:00:00
8    2016-06-03 18:00:00
9    2016-06-04 09:00:00
10   2016-06-04 11:00:00
11   2016-06-04 17:00:00
12   2016-06-05 08:00:00
13   2016-06-05 12:00:00
14   2016-06-05 18:00:00
15   2016-06-06 08:00:00
16   2016-06-06 12:00:00
17   2016-06-06 18:00:00
18   2016-06-07 08:00:00
19   2016-06-07 12:00:00
20   2016-06-07 18:00:00
21   2016-06-08 08:00:00
22   2016-06-08 12:00:00
23   2016-06-08 18:00:00
24   2016-06-09 08:00:00
25   2016-06-09 12:00:00
26   2016-06-09 18:00:00
Name: DateTime, dtype: datetime64[ns]

Likewise, you can also print the mmol/L column:

print data_frame['mmol/L']

You should see the following:

0      6.1
1      6.5
2      6.7
3      5.0
4      4.9
5      5.5
6      5.6
7      7.1
8      5.9
9      6.6
10     4.1
11     5.9
12     7.6
13     5.1
14     6.9
15     5.0
16     6.1
17     4.9
18     6.6
19     4.1
20     6.9
21     5.6
22     8.1
23    10.9
24     5.2
25     7.1
26     4.9
Name: mmol/L, dtype: float64

Visualizing the Data

Let’s now try to visualize the data by displaying a chart. For this purpose, let’s use matplotlib. Matplotlib is a plotting library for the Python language and is integrated right into pandas.

Add the following statements in bold to the existing Python script:

%matplotlib inline

import pandas as pd
import numpy as np

data_frame = pd.read_csv('readings.csv', index_col=0, parse_dates=[1])
print data_frame
print data_frame.index
print data_frame['DateTime']
print data_frame['mmol/L']

data_frame.plot(x='DateTime', y='mmol/L')

The “%matplotlib inline” statement instructs IPython notebook to plot the matplotlib chart inline. You can directly plot a chart using the dataframe’s plot() function. The x parameter specifies the column to use for the x-axis and the y parameter specifies the column to use for the y-axis.

This will display the chart as follows:



You can add a title to the chart by importing the matplotlib module and using the title() function:

%matplotlib inline

import pandas as pd
import numpy as np
import matplotlib.pyplot as plt

data_frame = pd.read_csv('readings.csv', index_col=0, parse_dates=[1])
print data_frame

print data_frame.index
print data_frame['DateTime']
print data_frame['mmol/L']

data_frame.plot(x='DateTime', y='mmol/L')
plt.title('Blood Glucose Readings for John', color='Red')

A title is now displayed for the chart:


By default, matplotlib will display a line chart. You can change the chart type by using the kind parameter:

%matplotlib inline

import pandas as pd
import numpy as np
import matplotlib.pyplot as plt

data_frame = pd.read_csv('readings.csv', index_col=0, parse_dates=[1])
print data_frame

print data_frame.index
print data_frame['DateTime']
print data_frame['mmol/L']

data_frame.plot(kind='bar', x='DateTime', y='mmol/L')
plt.title('Blood Glucose Readings for John', color='Red')

The chart is now changed to a barchart:



Besides displaying as a barchart, you can also display an area chart:

data_frame.plot(kind='area', x='DateTime', y='mmol/L')

The chart is now displayed as an area chart:



You can also set the color for the area chart by using the color parameter:

data_frame.plot(kind='area', x='DateTime', y='mmol/L', color='r')

The area is now in red:


Learning More


This article is just touching on the surface of what Python can do in the world of data analytics. To learn more about using Python for data analysis, come join my workshop (Introduction to Data Science using Python) at NDC Sydney 2016 on the 1-2 August 2016. See you there!
